Surface-Mounted Sensors
Category: Commercial and Residential- Sensors for lighting automation.
- Prevents electrical energy waste in unoccupied spaces or spaces with sufficient natural light.
- PIR-type sensor, Fresnel lenses, and photocell.
- ABS polymer chassis.
- Ambient light range: Adjustable between 10 lux and 2000 lux.
- Time delay: Adjustable from 10 seconds to 7 minutes.
- 360° detection angle.
- Sensor detection range of 3m (<25 °C)*.
- * The sensor requires a direct line of sight to the user. For the LED source, the time delay must be set to the maximum.
- * The detection range may be affected as the temperature increases, due to its operation with PIR infrared technology.
